• Compact & Portable: The whole unit weight (battery included) is approx. 1.2kg, suitable for aloft and field work.
  • Easy to Use:There are just a few concisely-defined keys,easy to be operated with only one hand.
  • Environmental Protection:This system is designed based on IP65 standard,suitable for complex industrial flaw detection environment.
  • Super-low Consumption:The configured Li-polymer battery can support up to 7-hour continuous operation.
  • Strong Performance:High resolution and penetration, achieving precise flaw detection from thin plates to large forged pieces.
>>Product Enquiry

FeaturesFunctionGalleryDownload

  • Max. sampling rate 240MHz; Measurement resolution 0.1mm.
  • Operating frequency range: 0.5~10MHz.
  • 20~2000Hz (step: 20Hz): avoid reverberation signals during flaw detection.
  • The AGC (auto gain control) function for efficient flaw detection.
  • The AVG/DGS curve works with echo compare function, making echo quantification of different distances and amplitudes more convenient.
  • The 5.7” color TFT LCD of wide viewing angle, high brightness and high definition delivers every clear detail.
  • Peak memory function facilitates quick scanning and measurement on workpieces.
  • Three different color schemes can meet the requirements of different application environments and habits.
  • Up to 300 sets of curve and waveform can be saved for various work pieces and flaw detection standards.

Data Storage


AVG/DGS Curve


DAC Curve


Detection on Large Forged Pieces


Peak Memory

×
